Underwater ship noise database

Zodiac

Motorboat

Vigo sea loch - Zone 3

Click for zoom

2013-07-23 16:40:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

Not available

50-100

Mean air temperature (ºC) 20
Maximum air temperature (ºC) 22,7
Minimum air temperature (ºC) 17
Mean relative humidity (%) 81
Maximum relative humidity (%) 93
Minimum relative humidity (%) 65
Dew temperature (ºC) 16,5
Cold hours (7 ºC base) (h) 0
Wind speed (km/h) 13,28
Streak (km/h) 43,34
Streak direction (Degrees) 4
Main wind direction(Degrees) 225
Rain (L/m2) 0

1:39

Vigo sea loch - Zone 3 - in front of Alcabre beach. Recording with better gain without clipping is presented. Other signals available. Signal in H3, zodiac passing.

Yacht (leaves)

Motorboat

Red lighthouse at the port

Click for zoom

2013-07-19 00:32:00

(1,2)(2,32)(2.5,3.5)

5.8

Not available

<50

Mean air temperature (ºC) 23,4
Maximum air temperature (ºC) 31
Minimum air temperature (ºC) 17,4
Mean relative humidity (%) 68
Maximum relative humidity (%) 100
Minimum relative humidity (%) 44
Dew temperature (ºC) 16,5
Cold hours (7 ºC base) (h) 0
Wind speed (km/h) 11,81
Streak (km/h) 36,94
Streak direction (Degrees) 2
Main wind direction(Degrees) 45
Rain (L/m2) 0

1:32

Considerable harbour noise. H2 not available. Unidentified yacht leaving port. Low signal.

Viking Chance

RORO

Vigo sea loch - Zone 3

Click for zoom

2013-07-23 18:42:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

AIS data

50-100

3:08

Vigo sea loch - Zone 3 - in front of Alcabre beach. Recording with better gain without clipping is presented. Other signals available. Signal in H3, big RORO passing followed by the pilot ship.

Tugboat (start-stop engine)

Tugboat

In front of ocean liners harbour

click for zoom

2013-07-19 09:32:00

(1,2)(2,32)(2.5,3.5)

5.8

Not available

<50

1:04

Small background noise from ship "Rio Caxil", there's also some harbor noise, H2 saturated, only H1 was considerate. Tugboat leaving dock starting and stopping the motor. Medium-good signal.

Small yacht

Motorboat

Vigo sea loch - Zone 3

Click for zoom

2013-07-23 18:21:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

Not available

<50

1:54

Vigo sea loch - Zone 3 - in front of Alcabre beach. Recording with better gain without clipping is presented. Other signals available. Signal in H2, 6m length yacht passing.

Saladino Primero

fishboat

Vigo sea loch - Zone 3

Click for zoom

2013-07-23 17:46:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

Not available

<50

2:25

Vigo sea loch - Zone 3 - in front of Alcabre beach. Recording with better gain without clipping is presented. Other signals available. Signal in H3, fishboat Saladino Primero passing.

Sailboat 2

Sailboat

Vigo sea loch - Zone 1

Click for zoom

2013-07-23 12:20:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

10.5

Not available

<50

0:19

Zone 1 - in front of Moaña. Recording with better gain without clipping is presented. Other signals available. H3 signal, sailboat (with engine) in the distance.

Sailboat (starts and leaves)

Sailboat

Red lighthouse at the port

Click for zoom

2013-07-19 12:17:00

(1,2)(2,32)(2.5,3.5)

5.8

Not available

<50

0:43

Considerable harbour noise. H2 not available Good signal. Starts engine and leaves port.

Sailboat

Vigo sea loch - Zone 1

Click for zoom

2013-07-23 12:20:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

10.5

Not available

<50

0:49

Zone 1 - in front of Moaña. Recording with better gain without clipping is presented. Other signals available. H3 signal, sailboat passing (without engine) really close. Considerable background noise.

Sailboat

Vigo sea loch - Zone 2

Click for zoom

2013-07-23 15:13:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

10.5

Not available

<50

4:57

Zone 2 - in front of Cangas. Choppy sea. Recording with better gain without clipping is presented. Other signals available. Signal in H3, recording of the measurements sailboat on his way back to hydrophone pick up.

Rada Uno (Passing)

Tugboat

Ocean liners harbour

Click or zoom

2013-07-10 00:00:00

(2),(4),(2.85)

9.1

Not available

<50

Mean air temperature (ºC) 18,9
Maximum air temperature (ºC) 20,5
Minimum air temperature (ºC) 17,4
Mean relative humidity (%) 95
Maximum relative humidity (%) 100
Minimum relative humidity (%) 87
Dew temperature (ºC) 18
Cold hours (7 ºC base) (h) 0
Wind speed (km/h) 11,66
Streak (km/h) 28,22
Streak direction (Degrees) 248
Main wind direction(Degrees) 270
Rain (L/m2) 0

2:22

First series of recordings. There is not in situ wind speed measures. Quite harbor noise.

Pirata de Salvora (leaves, 2nd take)

Passengers

Vigo sea loch - Zone 1

Click for zoom

2013-07-23 13:04:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

10.5

Not available

50-100

2:55

Zone 1 - in front of Moaña. Recording with better gain without clipping is presented. Other signals available. H3 signal, leaving the port. Medium-close take.

Pirata de Salvora (leaves)

Passengers

Vigo sea loch - Zone 1

Click for zoom

2013-07-23 12:04:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

10.5

Not available

50-100

1:08

Zone 1 - in front of Moaña. Recording with better gain without clipping is presented. Other signals available. H3 signal, leaving the port. Less speed than the arrive.

Pirata de Salvora (arrives)

Passengers

Vigo sea loch - Zone 1

Click for zoom

2013-07-23 12:40:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

10.5

Not available

50-100

2:41

Zone 1 - in front of Moaña. Recording with better gain without clipping is presented. Other signals available. H3 signal, recording of the port reaching including crossing speed and braking.

Pirata de Cies (Waiting)

Passengers

Cangas ships departure

Click for zoom

2013-07-10 00:00:00

(2),(4),(2.85)

4.8

AIS data

<50

1:00

First series of recordings. There is not in situ wind speed measures. Quite harbor noise. Waiting for passengers loading

Pirata de Cies (leaves)

Passengers

Red lighthouse at the port

Click for zoom

2013-07-19 00:22:00

(1,2)(2,32)(2.5,3.5)

5.8

AIS data

<50

0:58

Considerable harbour noise. H2 not available. Pirata de Cies leaves after a reversal maneuver.

Pirata de Cies (Entering)

Passengers

Cangas ships departure

Click for zoom

2013-07-10 12:26:00

(2),(4),(2.85)

4.8

AIS data

<50

3:27

First series of recordings. There is not in situ wind speed measures. Quite harbor noise. Entering the port for docking.

Pirata de Cies (arrives, interference)

Passengers

Red lighthouse at the port

Click for zoom

2013-07-19 00:08:00

(1,2)(2,32)(2.5,3.5)

5.8

AIS data

<50

0:51

Considerable harbour noise. H2 not available. Pirata de Cies arrives behind Mar de Cangas, Arrois leaves.

Pirata de Cies

Passengers

Vigo sea loch - Zone 2

Click for zoom

2013-07-23 14:13:00

(1,2,3)(2,16,64)(5.5,6.5,7.5)

10.5

AIS data

50-100

4:16

Zone 2 - in front of Cangas. Choppy sea. Recording with better gain without clipping is presented. Other signals available. Signal in H3, Pirata de Cies sailing to Cies islands.

Pilot ship

In front of ocean liners harbour

click for zoom

2013-07-19 09:37:00

(1,2)(2,32)(2.5,3.5)

5.8

Not available

<50

1:34

Small background noise from ship "Rio Caxil", there's also some harbor noise, H2 saturated, only H1 was considerate. Pilot ship arrives before Adventure of the Seas. Small signal.
